AWS Glue ETL

An out-of-the-box connector is available for AWS Glue ETL entities. It provides support for crawling Jobs, Workflow, Triggers, Crawlers, and lineage building for the above entities.

Connectivity Summary

The connectivity to AWS Glue ETL is via AWS Glue SDK, which is included in the platform.

The Glue SDK used by the connector is given below:

Driver / API	Version	Details
AWS Glue SDK	1.12.232	https://mvnrepository.com/artifact/com.amazonaws/aws-java-sdk-glue/1.12.232 Note: Latest version is 1.12.244.

Technical Specifications

The connector capabilities are shown below: The AWS Glue entities are created as datasets as Jobs, Workflows, Crawlers, and Triggers. We extract a job's script and build the lineage for it whereas for the crawlers, triggers, and workflows we extract the information of entities involved and build the associations accordingly.

Crawling

Feature	Supported Objects	Remarks
Crawling	Jobs
	Workflows
	Crawlers
	Triggers

Lineage Building

Lineage entities	Details
Jobs	In Progress
Workflows	Supported
Crawlers	Supported
Triggers	Supported

Pre-requisites:

To use the connector, the following need to be available:

• Connection details as specified in the following section should be available.

• An admin/service account, for crawling. The minimum privileges required are

Operation	Access Permission
Crawl Jobs	LIST, GET permission on Jobs
Crawl Workflows	LIST, GET permission on workflows
Crawl Crawlers	LIST, GET permission on crawlers
Crawl Triggers	LIST, GET permission on triggers

Connection Details

The following connection settings should be added for connecting to AWS Glue ETL:

Property	Details
Database Type	AWS Glue ETL
Connection Name	Select a Connection name for the AWS Glue ETL. The name that you specify is a reference name to easily identify your AWS Glue ETL connection in OvalEdge. Example: AWS Glue ETL Connection.
Authentication	Select the authentication type whether it is Role-based authentication or Basic Authentication.
Access key	Access key
Secret key	Secret key
Region	Region of Glue

Points to note:

AWS Glue ETL doesn’t support querying for the Glue data catalog from OvalEdge.

---
