Note: Latest version 8.3.1
| ## **Pre-requisites** To use the Elasticsearch Connector, the details specified in the following section should be available. * An admin/service account for crawling and profiling. * The minimum privileges required are: | Operation | Access Permission | | ----------------------- | ----------------- | | Connection validate | READ | | Crawl schemas | READ | | Crawl tables | READ | | Profile schemas, tables | READ | ## **Technical Specifications** The connector capabilities are shown below: ### **Crawling** | Feature | Supported Objects | Remarks | | ------------- | ----------------- | ------- | | **Crawling** | Tables | | | Table columns | All data types | | | Views | | | ### **Profiling** | Feature | Support | Remarks | | ---------------- | --------------------------------------------- | ------------------------------------------------- | | Table Profiling | Row count, Columns count, View sample data | Supports all data types | | View Profiling | Row count, Columns count, View sample data | View is treated as a table for profiling purposes | | Column Profiling | Min, Max, Null count, distinct, top 50 values | | | Sample Profiling | Supported | | ## **Connection Details** The following connection setting details should be added for connecting to an Elasticsearch database: | Property | Details | | ---------------------- | ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | Database Type | Elastic Search | | License Type | Standard | | Connection Name |Select a Connection name for the Elasticsearch database. The name that you specify is a reference name to easily identify the Elasticsearch database connection in OvalEdge.
Example: Elastic Search Connection DB1
| | Host/ IP /AES Endpoint | | | Username | User account login credential | | Password | Password for the user | ### **Role-based Authentication** The following are the field attributes required for the connection of Elasticsearch for role-based authentication. | Property | Details | | ----------------------- | ------------------ | | Region | Region of database | | Is Role based Auth(Y/N) | provide role ARN | | Role ARN | Region of database | | Access key | Access Key | | Secret key | Secret Key | Once connectivity is established, additional configurations for crawling and profiling can be specified: | Crawler configurations Settings | Details | | -------------------------------- | ---------------------------------------------------------------------------------- | | Tables, views and Columns | If the checkbox is selected it will crawl the tables and columns in Elasticsearch. | |Include Table
Regex
| It catalogs the table based on the regex search pattern added. | | Exclude Table Regex | It doesn’t catalog the table based on the regex search pattern added. | ### **Profiler Settings:** | Profiler Settings | Details | | ------------------- | ----------------------------------------------------------------------------------------------------------------------------- | | Profile Type | **Sample** - Sample profiling will be performed based on sample profile size **Disabled** - profiling is disabled completely. | | No. of threads | No of threads used for profiling | | Query TimeOut | It is wait time for query response | | Rowcount constraint | If it is checked the profiling performed based the rowcount limit | | Profile rules | It will include/ exclude the tables to perform profiling based on regex search pattern added. | *** Copyright © 2025, OvalEdge LLC, Peachtree Corners GA USA
