# Exasol

This article outlines the integration with the Apache Kafka connector, enabling streamlined metadata management through crawling, profiling, data preview, and lineage building (Auto & Manual). It also ensures secure authentication via Credential Manager.

<figure><img src="/files/37DNqxSmaTkfuopIvsXl" alt=""><figcaption></figcaption></figure>

## Overview

### Connector Details

| Connector Category                                                         | RDBMS                    |
| -------------------------------------------------------------------------- | ------------------------ |
| OvalEdge Release Supported                                                 | Release6.3 to Release7.2 |
| <p>Connectivity</p><p>\[How the connection is established with Exasol]</p> | JDBC                     |

### Connector Features

| Feature                                      | Availability |
| -------------------------------------------- | :----------: |
| Crawling                                     |       ✅      |
| Delta Crawling                               |       ❌      |
| Profiling                                    |       ✅      |
| Query Sheet                                  |       ✅      |
| Data Preview                                 |       ✅      |
| Auto Lineage                                 |       ✅      |
| Manual Lineage                               |       ✅      |
| Secure Authentication via Credential Manager |       ✅      |
| Data Quality                                 |       ✅      |
| DAM (Data Access Management)                 |       ❌      |
| Bridge                                       |       ✅      |

### Metadata Mapping

The following objects are crawled from the Exasol and mapped to the corresponding UI assets.

| Exasol Object | Exasol Attribute    | OvalEdge Attribute | OvalEdge Category | OvalEdge Type      |
| ------------- | ------------------- | ------------------ | ----------------- | ------------------ |
| Table         | Table Name          | Table              | Tables            | Table              |
| Table         | Table Type          | Type               | Tables            | Table              |
| Table         | Table Comments      | Source Description | Descriptions      | Source Description |
| Columns       | Column Name         | Column             | Table Columns     | Columns            |
| Columns       | Data Type           | Column Type        | Table Columns     | Columns            |
| Columns       | Description         | Source Description | Table Columns     | Columns            |
| Columns       | Ordinal Position    | Column Position    | Table Columns     | Columns            |
| Columns       | Length              | Data Type Size     | Table Columns     | Columns            |
| Views         | View Name           | View               | Tables            | Views              |
| Views         | Text                | View Query         | Views             | Views              |
| Procedures    | Routine\_Name       | Name               | Procedures        | Procedures         |
| Procedures    | Description         | Source Description | Descriptions      | Procedures         |
| Procedures    | Routine\_Definition | Procedure          | Procedures        | Procedures         |
| Functions     | Routine\_Name       | Name               | Functions         | Functions          |
| Functions     | Routine\_Definition | Function           | Functions         | Functions          |
| Functions     | Description         | Source Description | Descriptions      | Functions          |
| Triggers      | Trigger Name        | Name               | Triggers          | Triggers           |
| Triggers      | Trigger Definition  | Trigger Data       | Triggers          | Triggers           |
| Triggers      | Trigger Type        | Type               | Triggers          | Triggers           |

## Set up a Connection

### Prerequisites

The prerequisites to establish a connection:

### **Whitelisting Ports**

Whitelist the inbound port 8563 to allow OvalEdge to connect to the Exasol Server database.

{% hint style="warning" %}
Exasol uses port 8563 by default. When a different port is configured, specify the updated port number during connection setup, whitelist the port, and establish proper communication between the system and the Exasol Server.
{% endhint %}

### Service Account User Permissions

{% hint style="warning" %}
Use a dedicated service account to establish the connection to the data source, configured with the following minimum set of permissions.
{% endhint %}

{% hint style="info" %}
**👨‍💻 Who can provide these permissions?** The Exasol administrator grants these permissions, as standard accounts may not have the required access to assign them independently.
{% endhint %}

<table><thead><tr><th width="198">Objects</th><th width="328">System Tables</th><th>Access Permission</th></tr></thead><tbody><tr><td>Schema</td><td><ul><li>sys.schema</li><li>extended_properties</li></ul></td><td>Select</td></tr><tr><td>Tables</td><td><ul><li>Information_Schema.Tables</li><li>fn_listextendedproperty</li></ul></td><td>Select</td></tr></tbody></table>

### Connection Configuration Steps

{% hint style="warning" %}
Users must have the Connector Creator role to configure a new connection.
{% endhint %}

1. Log in to OvalEdge, go to Administration > Connectors, click + **(New Connector)**, search for **Exasol**, and complete the required parameters.

{% hint style="info" %}
Fields marked with an asterisk (\*) are mandatory for establishing a connection.
{% endhint %}

<table><thead><tr><th width="221">Field Name</th><th>Description</th></tr></thead><tbody><tr><td>Connector Type</td><td>By default, "Exasol" is displayed as the selected connector type.</td></tr><tr><td>Credential Manager*</td><td><p>Select the desired credentials manager from the drop-down list. Relevant parameters will be displayed based on the selection.</p><p>Supported Credential Managers:</p><ul><li>Database</li><li>HashiCorp</li><li>AWS Secrets Manager</li><li>Azure Key Vault</li></ul></td></tr><tr><td>License Add-On</td><td><p></p><p></p><ul><li>Select the Auto Lineage Add-On checkbox to automatically build data lineage.</li></ul></td></tr><tr><td>Connector Name*</td><td><p>Enter a unique name for the Exasol connection              </p><p>(Example: "Exasol_Prod").</p></td></tr><tr><td>Connector Environment</td><td>Select the environment (Example: PROD, STG) configured for the connector.</td></tr><tr><td>Connector Description</td><td>Enter the description related to the connector.</td></tr><tr><td>Server*</td><td>Enter the IP address of the server where Exasol is hosted.</td></tr><tr><td>Port*</td><td>Exasol uses port 8563 by default. The port number can be modified as needed.</td></tr><tr><td>Database*</td><td><p>The ‘Database’ field defines the default schema that the connector uses to connect to the Exasol server.</p><p>Example: If the target database is sales_db, enter sales_db to connect directly instead of the default schema.</p></td></tr><tr><td>Driver*</td><td>By default, Exasol uses ‘com.exasol.jdbc.jdbc41.EXADriver.’ This field is not editable.</td></tr><tr><td>Username* </td><td>Enter the Username for the  Exasol server.</td></tr><tr><td>Password* </td><td>Enter the Password associated with the Exasol Username.</td></tr><tr><td>Connection String</td><td><p>Configure the connection string for the Exasol server:</p><ul><li>Automatic Mode: The system generates a connection string based on the provided credentials.</li><li>Manual Mode: Enter a valid connection string manually.</li></ul><p>Replace placeholders with actual server details:</p><ul><li>{server} refers to the Exasol host or IP address.</li><li>{sid} refers to the database name (schema).<br></li></ul><p>Authentication Plugins:<br>jdbc:exa:{server}:8563;schema={sid}</p><p></p><p>This is the default JDBC connection string used for connecting to Exasol. The schema parameter specifies the default schema to use after the connection is established.</p></td></tr><tr><td>Plugin Server</td><td>Enter the server name when running as a plugin server.</td></tr><tr><td>Plugin Port</td><td>Enter the port number on which the plugin is running.</td></tr></tbody></table>

**Default Governance Roles**

<table data-header-hidden><thead><tr><th width="221"></th><th></th></tr></thead><tbody><tr><td>Default Governance Roles*</td><td>Select the appropriate users or teams for each governance role from the drop-down list. All users and teams configured in OvalEdge Security are displayed for selection.</td></tr></tbody></table>

**Admin Roles**

<table data-header-hidden><thead><tr><th width="221"></th><th></th></tr></thead><tbody><tr><td>Admin Roles*</td><td>Select one or more users from the dropdown list for Integration Admin and Security &#x26; Governance Admin. All users configured in OvalEdge Security are available for selection.</td></tr></tbody></table>

**Number of Archive Objects**

<table data-header-hidden><thead><tr><th width="220"></th><th></th></tr></thead><tbody><tr><td>Number of Archive Objects*</td><td><p>This shows the number of recent metadata changes to a dataset at the source. By default, it is off. To enable it, toggle the Archive button and specify the number of objects to archive.</p><p>Example: Setting it to 4 retrieves the last four changes, displayed in the 'Version' column of the 'Metadata Changes' module.</p></td></tr></tbody></table>

**Bridge**

<table data-header-hidden><thead><tr><th width="221"></th><th></th></tr></thead><tbody><tr><td>Select Bridge*</td><td><p>If applicable, select the bridge from the drop-down list.</p><p>The drop-down list displays all active bridges configured in OvalEdge. These bridges enable communication between data sources and OvalEdge without altering firewall rules.</p></td></tr></tbody></table>

2. After entering all connection details, the following actions can be performed:
   * Click **Validate** to verify the connection.
   * Click **Save** to store the connection for future use.
   * Click **Save & Configure** to apply additional settings before saving.
3. The saved connection will appear on the Connectors home page.

## Manage Connector Operations

### Crawl/Profile

{% hint style="warning" %}
To perform crawl and profile operations, users must be assigned the Integration Admin role.
{% endhint %}

The **Crawl/Profile** button allows users to select one or more schemas for crawling and profiling.&#x20;

1. Navigate to the Connectors page and click **Crawl/Profile**.
2. Select the schemas to crawl.
3. The **Crawl** option is selected by default. Click the **Crawl & Profile** radio button to enable both operations.
4. Click **Run** to collect metadata from the connected source and load it into the **Data Catalog**.
5. After a successful crawl, the information appears in the **Data Catalog > Databases** tab.

The **Schedule** checkbox allows automated crawling and profiling at defined intervals, from a minute to a year.

1. Click the **Schedule** checkbox to enable the **Select Period** drop-down.
2. Select a time period for the operation from the drop-down menu.
3. Click **Schedule** to initiate metadata collection from the connected source.

The system will automatically execute the selected operation (**Crawl** or **Crawl & Profile**) at the scheduled time.

### Other Operations

The Connectors page in OvalEdge provides a centralized view of all configured connectors, including their health status.

**Managing connectors includes:**

* **Connectors Health**: Displays the current status of each connector, with a green icon for active connections and a red icon for inactive connections, helping monitor connectivity to data sources.
* **Viewing**: Click the **Eye** icon next to the connector name to view connector details, including Tables, Views, and Columns.&#x20;

**Nine Dots Menu Options:**

To view, edit, validate, configure, or delete connectors, click on the **Nine Dots** menu.

* **Edit Connector**: Update and revalidate the data source.
* **Validate Connector**: Check the integrity of the connection.
* **Settings**: Modify connector settings.
  * **Crawler**: Configure data extraction.
  * **Profiler**: Customize data profiling rules and methods.
  * **Access Instructions**: Add notes on how data can be accessed.
  * **Business Glossary Settings**: Manage term associations at the connector level.
  * **Others**: Configure notification recipients for metadata changes.
* **Build Lineage**: Automatically build data lineage using source code parsing.
* **Delete Connector**: Remove a connector with confirmation.

### Connectivity Troubleshooting

If incorrect parameters are entered, error messages may appear. Ensure all inputs are accurate to resolve these issues. If issues persist, contact the assigned support team.

<table><thead><tr><th width="85.11114501953125">S.No.</th><th width="225.22216796875">Error Message(s)</th><th>Error Description &#x26; Resolution</th></tr></thead><tbody><tr><td>1</td><td>Error while validating EXASOL connection | Root cause: Connect timed out</td><td><p><strong>Error Description</strong>: The EXASOL connection validation failed because the system could not establish a connection within the defined timeout period.<br></p><p><strong>Resolution</strong>: Verify the EXASOL server’s network connectivity, firewall settings, and port configuration, then retry the connection to ensure proper connectivity.</p></td></tr></tbody></table>

***
